SANY
Counterweight bar package 2
Article number: 110560-23
Specification
Lighting configuration
| Flashlight | 4 pcs |
|---|---|
| Position light, red | 6 pcs |
| Work light bracket | 2 pcs |
- Finish
- Painted
- Package level
- Package 2
- Mounting
- Bar for mounting on the counterweight
Package levels are the factory's kit designations.
Machine fitment
Manufacturer fitment specification, quoted verbatim:
SY215c-LC
Model ranges are shown exactly as the manufacturer publishes them. Not sure about your machine? Ask us: checking fitment is free.
€3,048 excl. VAT · €3,688.08 incl. VAT (NL 21%)
Prices excl. VAT. B2B: reverse-charge VAT possible with a valid EU VAT number.
Ordering for a fleet, need an invoice first, or want to confirm fitment? Request a quote and we reply within one working day.
Powder coating in your colour
This bar can be powder coated in any RAL colour of your choice, matched to your machine or fleet. Powder coating is always quoted individually: request a quote and mention your preferred colour.
Request a quote with powder coatingMounting, wiring & use
Open printable manualWiring
- Wiring 1
- Connect to switch fĘr funktion
- Wiring 2
- Connector DT06-08SA 1. Flashlight (+) 2. Flashlight (-) 3. Flashlight Dimmer. (+) 4. Position light (+) 5. Position light (-) 6. Work light (+) 7. Work light (-) 8. Free
Flash patterns
9 - Single (all) (R65 - EU Certified)
Show all programmable flash patterns
- 0 - Random (default)
- 1 - Single (split)
- 2 - Double (split)
- 3 - Quad (split)
- 4 - Quint (split)
- 5 - Mega (split)
- 6 - Ultra (split)
- 7 - Single-Quad (split)
- 8 - Single H/L (split)
- 9 - Single (all) (R65 - EU Certified)
- 10 - Single (all) (SAE)
- 11 - Double (all)
- 12 - Quad (all)
- 13 - Quint (all)
- 14 - Mega (all)
- 15 - Ultra (all)
- 16 - Single-Quad (all)
- 17 - Single H/L (all)
- 18 - Steady 2 (California)
- 19 - Steady 4 (all)
Source: factory product sheet PD00269 (rev. A), translated from Swedish. The original is archived. Translated from the supplier's Swedish documentation.
How our bars are built
Video from the factory showing how the aluminium bars are made.
